Запчасти Komatsu PC1000SP-1 ГУСЕНИЧНАЯ РАМА (С КРЫШКОЙ) ХОДОВАЯ

1

21N-30-17311

FRAME,CENTER

|1

21N-30-17310

FRAME,CENTER

|1

21N-30-11690

FRAME,CENTER (SP)

2

21N-30-11410

PLATE

3

01010-51435

BOLT

4

195-71-32220

WASHER

5

21N-30-11360

COVER

6

21N-30-11370

COVER

7

21N-30-11380

COVER

8

21N-30-11390

COVER

9

01010-51435

BOLT

10

01643-31445

WASHER

11

21N-30-11211

FRAME

12

01010-51255

BOLT

13

01643-31232

WASHER

14

21N-30-11220

SEAL

15

205-30-71181

COVER

16

205-30-71191

GASKET

17

01010-51225

BOLT

18

01643-31232

WASHER

19

21N-30-17121

FRAME,L.H.

|19

21N-30-17131

FRAME,R.H.

20

21N-30-11150

SUPPORT (WELDED)

21

209-30-11220

PLATE

22

01010-51225

BOLT

23

01643-31232

WASHER

24

21N-30-17530

PLATE

25

01010-83060

BOLT

26

01643-33080

WASHER

27

21N-30-17141

GUARD

28

01011-83030

BOLT

29

208-30-11971

SPACER

30

21N-30-11190

BOLT

31

21N-30-11170

SPACER

32

21N-30-11160

COLLAR

33

21N-30-11230

PLATE

34

21N-30-11180

BOLT

35

07049-03038

PLUG

36

21N-30-11180

BOLT

37

21N-30-11171

SPACER
