Запчасти Komatsu PC1000SP-1 ЦИЛИНДР КОВША РАБОЧЕЕ ОБОРУДОВАНИЕ (ЭКСКАВАТ.)

G-1

21N-63-X2060

CYLINDER GROUP

|1

21N-63-02060

CYLINDER ASS'Y

1

21N-63-72340

CYLINDER

2

21N-63-72320

ROD

3

21T-72-15860

BUSHING

4

21T-72-15870

SEAL,DUST (KIT)

5

707-46-14010

BUSHING

6

01010-83095

BOLT

7

07179-14180

RING,SNAP

8

566-63-22241

SEAL,DUST (KIT)

9

707-28-22540

HEAD,CYLINDER

10

707-51-16130

PACKING,ROD (KIT)

11

707-51-16630

RING,BUFFER (KIT)

12

07000-15220

O-RING (KIT)

13

707-35-92300

RING,BACK-UP (KIT)

14

707-52-91350

BUSHING

15

07000-15220

O-RING (KIT)

16

07001-05220

RING,BACK-UP (KIT)

17

707-71-11710

RING

18

707-71-31720

COLLAR

19

707-71-51732

PLUNGER

20

707-35-91440

RING,BACK-UP (KIT)

|21

707-91-02211

PISTON SUB ASS'Y

21

PISTON

22

SEAT

23

VALVE,PISTON

24

SPRING

25

VALVE,PISTON

26

707-40-22970

SPACER

27

707-37-22030

PISTON

28

07043-00108

PLUG

29

07000-15135

O-RING (KIT)

30

707-39-22820

RING,WEAR (KIT)

31

707-44-22280

RING,PISTON (KIT)

32

01252-31695

BOLT

33

07000-13048

O-RING (KIT)

34

21N-63-72370

TUBE

35

21N-63-72380

TUBE

36

01010-51240

BOLT

37

01643-31232

WASHER

38

21N-62-18440

BAND

39

21N-62-18420

BRACKET

40

07283-24346

CLIP

41

01643-31032

WASHER

42

01599-01011

NUT

43

07378-11410

HEAD

44

07000-13048

O-RING (KIT)

45

01010-51455

BOLT

46

01643-31445

WASHER

47

07371-51470

FLANGE

48

01010-51450

BOLT

49

01643-31445

WASHER

|50

707-99-78630

SERVICE KIT
