Запчасти Komatsu PC1000LC-1 ЦИЛИНДР КОВША (ДЛЯ УДЛИНН. РУКОЯТИ) РАБОЧЕЕ ОБОРУДОВАНИЕ (ЭКСКАВАТ.)
№
Артикул
Название
Примечание
Количество
G-1
21N-63-X2052
CYLINDER GROUP
G-1
21N-63-X2051
CYLINDER GROUP
G-1
21N-63-X2050
CYLINDER GROUP
|$4
21N-63-02052
CYLINDER ASS'Y
|$5
21N-63-02051
CYLINDER ASS'Y
|$6
21N-63-02050
CYLINDER ASS'Y
1
21N-63-72241
CYLINDER
1
21N-63-72240
CYLINDER
2
21N-63-72221
ROD
2
21N-63-72220
ROD
3
21T-72-15860
BUSHING
4
21T-72-15870
SEAL,DUST (KIT)
5
707-46-14010
BUSHING
5A
707-46-13010
BUSHING
6
01010-82790
BOLT
7
07179-14160
RING,SNAP
7
707-75-14012
RING,SNAP
8
198-63-93170
SEAL,DUST (KIT)
9
707-28-20550
HEAD,CYLINDER
9
707-28-20540
HEAD,CYLINDER
10
707-51-14130
PACKING,ROD (KIT)
11
707-51-14630
RING,BUFFER (KIT)
12
07000-15195
O-RING (KIT)
13
707-35-92050
RING,BACK-UP (KIT)
14
707-52-91150
BUSHING
14
707-52-11410
BUSHING
15
07000-15195
O-RING (KIT)
16
07001-05195
RING,BACK-UP (KIT)
17
707-71-11450
RING
18
707-71-31460
COLLAR
19
707-71-51471
PLUNGER
19
707-71-51470
PLUNGER
19
707-71-51460
PLUNGER
19A
707-40-20910
RETAINER
20
707-35-52860
RING,BACK-UP (KIT)
|$36
707-91-02062
PISTON ASS'Y
|$37
707-91-02061
PISTON ASS'Y
21
PISTON
21
PISTON
22
SEAT
23
VALVE,PISTON
24
SPRING
25
VALVE,PISTON
26
707-40-20970
SPACER
27
707-37-20020
PISTON
28
07043-00108
PLUG
29
07000-12115
O-RING (KIT)
30
707-39-20820
RING,WEAR (KIT)
31
707-44-20180
RING,PISTON (KIT)
31
707-44-20080
RING,PISTON (KIT)
32
01252-31490
BOLT
33
07000-13048
O-RING (KIT)
33A
07000-13038
O-RING (KIT)
34
21N-63-72271
TUBE
34
21N-63-72270
TUBE
35
21N-63-72280
TUBE
36
01010-81240
BOLT
37
01643-31232
WASHER
38
707-88-96110
BAND
39
707-88-96090
BRACKET
40
07283-24346
CLIP
41
01643-31032
WASHER
42
01599-01011
NUT
43
07378-11410
HEAD
44
07000-13048
O-RING (KIT)
45
01010-81455
BOLT
46
01643-31445
WASHER
47
07371-51470
FLANGE
48
01010-81280
BOLT
49
01643-31232
WASHER
50
01010-81450
BOLT
51
01643-31445
WASHER
|$74
707-99-77230
SERVICE KIT
Выбрано товаров: 73
