Запчасти Komatsu PC100-6S ОСНОВН. КЛАПАН (7-КЛАПАН) (9/)(№-) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

Схема запчастей Komatsu PC100-6S - ОСНОВН. КЛАПАН (7-КЛАПАН) (9/)(№-) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ
1
2
3
4
5
6
7
8
9
10
11
12
13
14
14
14
14
15
15
16
17
18
18
19
19
20
20
21
21
22
23
24
25
26
27
27
28
28
29
30
31
31
32
33
34
35
36
37
38
39
40

Артикул

Название

Примечание

Количество

|1

723-57-12305

CONTROL VALVE

|1

723-57-12304

CONTROL VALVE

|1

723-57-12303

CONTROL VALVE

|1

723-57-12302

CONTROL VALVE

|1

723-57-12301

CONTROL VALVE

|1

723-57-12300

CONTROL VALVE

|1

723-57-11303

CONTROL VALVE

|1

723-57-11302

CONTROL VALVE

|1

723-57-11301

CONTROL VALVE

|1

723-57-11300

CONTROL VALVE

|1

723-50-51400

VALVE ASS'Y

|1

723-50-51300

VALVE ASS'Y

|1

723-50-51100

VALVE ASS'Y

1

BLOCK

2

SPOOL

|2

SPOOL

|2

SPOOL

3

723-50-51230

SPRING

|3

723-50-51130

SPRING

4

723-50-51140

PLUG

5

07002-11623

O-RING

6

723-50-51150

FLANGE

7

07000-12011

O-RING

8

07000-11007

O-RING

9

01252-60620

BOLT

10

BALL

11

723-50-51160

PLUG

12

07000-11003

O-RING

13

07002-10823

O-RING

14

SCREW

15

07000-11008

O-RING

|16

723-50-52200

VALVE ASS'Y

|16

723-50-52100

VALVE ASS'Y

16

BLOCK

17

SPOOL

18

723-50-52130

RETAINER

19

723-50-52150

SPRING

|19

723-50-52140

SPRING

20

723-56-31630

PLUG

21

07002-11623

O-RING

22

BALL

23

723-50-51160

PLUG

24

07000-11003

O-RING

25

07002-10823

O-RING

26

723-56-41620

ORIFICE

27

723-11-18190

PLUG

28

07002-11023

O-RING

29

SCREW

30

07000-11008

O-RING

31

07000-11007

O-RING

|32

723-50-54100

VALVE ASS'Y

32

723-50-54110

BLOCK

33

723-56-31610

VALVE

34

723-56-31620

SPRING

35

723-56-31630

PLUG

36

07002-11623

O-RING

37

723-11-18190

PLUG

38

07002-11023

O-RING

39

07000-11009

O-RING

40

708-2L-25490

O-RING

Выбрано товаров: 60
