Запчасти Komatsu PC100-6 ОСНОВН. КЛАПАН (-КЛАПАН) (/)(№-) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|$9

723-56-12104

CONTROL VALVE

|$10

723-56-12103

CONTROL VALVE

|$11

723-56-12102

CONTROL VALVE

|$12

723-56-12101

CONTROL VALVE

|$13

723-56-12100

CONTROL VALVE

|$14

723-56-11103

CONTROL VALVE

|$15

723-56-11102

CONTROL VALVE

|$16

723-56-11101

CONTROL VALVE

|$17

723-56-11100

CONTROL VALVE

|$19

723-50-53102

VALVE ASS'Y

|$20

723-50-53101

VALVE ASS'Y

1

BLOCK

2

VALVE

2

VALVE

3

702-21-35130

SEAL

4

723-50-53130

SPRING

5

723-50-53230

SPACER

6

PISTON

6

PISTON

7

SEAL

7

SEAL

8

SLEEVE

8

SLEEVE

9

07000-12010

O-RING

10

07001-02010

RING

11

07000-12012

O-RING

12

07001-02012

RING,BACK-UP

13

723-50-53170

SEAT

14

07000-12016

O-RING

15

PISTON

16

723-50-53190

SPRING

17

723-50-53270

PLATE

17

723-50-53210

PLATE

18

723-50-53260

RETAINER

18

723-50-53222

RETAINER

19

07000-12015

O-RING

20

07000-13030

O-RING

21

01252-60630

BOLT

22

PLUG

23

700-13-31161

O-RING

24

07000-11007

O-RING
