Запчасти Komatsu PC100-6 СТРЕЛА (СТРЕЛА¤ РАБОЧ. ОСВЕЩЕНИЕ И ПАЛЕЦ) (ДЛЯ АВТОМАТИЧ. СМАЗ.)(№7-) РАБОЧЕЕ ОБОРУДОВАНИЕ

|$2

202-70-00913

BOOM ASS'Y

|$3

202-70-00912

BOOM ASS'Y

1

BOOM

2

203-70-51221

SEAT (WELDED)

3

203-70-61C60

SEAT (WELDED)

4

203-70-51221

SEAT (WELDED)

5

203-70-61790

PLATE (WELDED)

6

203-70-61C60

SEAT (WELDED)

7

203-70-51260

SEAT (WELDED)

8

203-70-61780

PLATE (WELDED)

9

203-70-66110

BUSHING

9

203-70-56121

BUSHING

10

07145-00070

SEAL,DUST

11

07145-00070

SEAL,DUST

12

20Y-06-25310

WORKING LAMP ASS'Y

12

20Y-06-21480

WORKING LAMP ASS'Y

12

421-06-23330

BULB, 70W

13

20Y-06-21551

BRACKET

13

20Y-06-21550

BRACKET

14

01010-81225

BOLT

14

01010-51225

BOLT

15

01643-31232

WASHER

16

203-06-57230

WIRE

17

08034-40521

BAND

17

203-06-56570

BAND

18

08034-20414

BAND

19

01010-81230

BOLT

20

01643-31232

WASHER

21

202-70-61210

PIN

22

205-70-66580

PLATE

22

203-46-56270

PLATE

23

01010-81230

BOLT

23

01010-51230

BOLT

24

01643-31232

WASHER

25

20U-70-31340

SPACER, 1.0MM

25

203-70-11210

SPACER, 1.0MM

25

20U-70-31330

SPACER, 0.5MM

25

203-70-34270

SPACER, 0.5MM

26

203-70-42121

PIN

27

205-70-66580

PLATE

27

203-46-56270

PLATE

28

01010-81230

BOLT

28

01010-51230

BOLT

29

01643-31232

WASHER

30

203-70-41461

SPACER

30

203-70-41460

SPACER, 1.0MM
