Запчасти Komatsu PC100-6 СТРЕЛА (СТРЕЛА¤ РАБОЧ. ОСВЕЩЕНИЕ И ПАЛЕЦ)(№7-) РАБОЧЕЕ ОБОРУДОВАНИЕ

|$2

202-70-01010

BOOM ASS'Y

|$3

202-70-00712

BOOM ASS'Y

1

BOOM

2

203-70-51221

SEAT (WELDED)

3

203-70-61780

PLATE (WELDED)

4

203-70-61C60

SEAT (WELDED)

5

203-70-51260

SEAT (WELDED)

6

203-70-61310

PLATE (WELDED)

7

203-70-61C60

SEAT (WELDED)

8

203-70-51221

SEAT (WELDED)

9

203-70-61790

PLATE (WELDED)

10

203-70-66110

BUSHING

10

203-70-56121

BUSHING

11

07145-00070

SEAL,DUST

12

07145-00070

SEAL,DUST

13

20Y-06-25310

WORKING LAMP ASS'Y

13

20Y-06-21480

WORKING LAMP ASS'Y

13

421-06-23330

BULB, 70W

14

20Y-06-21551

BRACKET

14

20Y-06-21550

BRACKET

15

01010-81225

BOLT

16

01643-31232

WASHER

17

203-06-57230

WIRE

18

08034-40521

BAND

18

203-06-56570

BAND

19

08034-20414

BAND

20

01010-81230

BOLT

21

01643-31232

WASHER

22

202-70-61210

PIN

23

205-70-66580

PLATE

23

203-46-56270

PLATE

24

01010-81230

BOLT

25

01643-31232

WASHER

26

20U-70-31340

SPACER, 1.0MM

26

203-70-11210

SPACER, 1.0MM

26

20U-70-31330

SPACER, 0.5MM

26

203-70-34270

SPACER, 0.5MM

27

203-70-42121

PIN

28

205-70-66580

PLATE

28

203-46-56270

PLATE

29

01010-81230

BOLT

30

01643-31232

WASHER

31

203-70-41461

SPACER

31

203-70-41460

SPACER, 1.0MM
