Запчасти Komatsu PC10-7 ГОЛОВКА ЦИЛИНДРОВ ДВИГАТЕЛЬ

\0

871070013

ENGINE, ASSY.

1

YMR000682

PIPE

2

YMR000092

LIFTER

3

YMR000401

BOLT

4

YMR001107

HEAD,ASSY.

8

YMR000962

GUIDE VALVE

10

YMR000953

STUD

11

YMR000437

PLUG

12

YMR000954

VALVE, INLET

13

YMR000955

VALVE EXHAUST

14

YMR000956

SPRING, VALVE

15

YMR000957

RETAINER, SPRING

16

YMR000659

COTTER

17

YMR000660

SEAL, VALVE STEM

18

YMR000661

SEAL, VALVE STEM

19

YMR000662

CAP VALVE

20

YMR000365

PEG

21

YMR001128

SUPPORT ASSY.,ROCKER

22

YMR000959

COTTER

25

YMR000203

SUPPORT

26

YMR000204

SUPPORT

27

YMR000169

SPRING

28

YMR001108

ROCKER SHAFT

29

YMR000168

TAPPET

31

YMR000173

NUT

32

YMR000423

STUD

33

YMR000961

PROTECTION, NOZZLE

34

YMR000021

SEAT, NOZZLE

35

YMR000022

RETAINER

36

YMR000404

SCREW

37

YMR000408

SCREW

38

YMR000424

NUT

39

YMR000963

BONNEY ASSY.,HEAD

40

YMR000078

CAP, LUB. OIL SUPPLY

41

YMR000164

COVER, BREATHER

42

YMR000165

SPLASH-GUARD

43

YMR000166

PROTECTION

46

YMR000964

GASKET

47

YMR000384

O-RING

48

YMR000389

O-RING

49

YMR000402

SCREW

50

YMR000080

KNOB

51

YMR000382

O-RING
