Запчасти Komatsu PC10-7 ТОПЛ. НАСОС ДВИГАТЕЛЬ

\0

871070013

ENGINE, ASSY.

1

YMR001118

PUMP, ASSY.

5

YMR000206

STUD

6

YMR000024

CAMSHAFT

8

YMR000207

BEARING

9

YMR000208

COVER

10

YMR000075

KEY

11

YMR001119

PLUNGER W/BARREL

14

YMR000209

PIN

15

YMR000350

RETAINER, SPRING

16

YMR000210

SEAT, NOZZLE SPRING

17

YMR000095

SPRING

18

YMR000211

TAPPET, ASSY

25

YMR000213

LOCKING, TAPPET

26

YMR000214

O-RING

27

YMR000288

VALVE DELIVERY

30

YMR000215

SPRING

31

YMR000216

GUARD, DELIVERY VALVE

32

YMR000087

GASKET

33

YMR000088

O-RING

34

YMR000217

STOPPER

35

YMR000218

LOCKING (A)

36

YMR000219

LOCKING (B)

37

YMR000220

DEFLECTOR

38

YMR000221

CHECK BOLT

39

YMR000222

PLUG

40

YMR000223

KIT, SHIM

45

YMR000224

RACK

46

YMR000225

BUSHING

47

YMR000226

SPACER

48

YMR000227

RING, SNAP

49

YMR000228

PINION

50

YMR000074

SCREW

51

YMR000351

PINION

52

YMR000229

PLUG

53

YMR000230

O-RING

54

YMR000231

SPRING

55

YMR000232

KIT, SHIM

74

YMR000233

COVER

75

YMR000234

GASKET

76

YMR000235

COVER

77

YMR000236

GASKET

78

YMR000237

LOCKING, RACK

79

YMR000260

PLATE, CAUTION

80

YMR000238

SPACER T=3.25

81

YMR000239

SPACER T=1.5

82

YMR000680

SPRING WASHER

83

YMR001016

SPRING WASHER

84

YMR000364

PEG

85

YMR000723

BEARING

86

YMR000387

O-RING

87

YMR000393

SCREW

88

YMR000394

SCREW

89

YMR000415

SCREW

90

YMR000428

NUT

91

YMR001017

GASKET

94

YMR000240

GASKET

95

YMR000480

PUMP, ASSY.
