Запчасти Komatsu PC10-7 РЕГУЛЯТОР ДВИГАТЕЛЬ

\0

871070013

ENGINE, ASSY.

\0

YMR001118

PUMP, ASSY.

\0

REGULATOR, ASSY.

2

YMR000214

O-RING

5

YMR001120

GASKET

6

YMR001121

COVER

7

YMR001122

GASKET

8

YMR000245

LINK L=30 (0)

9

YMR000246

LINK L=31 (1)

10

YMR000247

LINK L=30.5 (0.5)

11

YMR000248

WEIGHT ASSY., GOVERNOR

15

YMR000249

SLEEVE

16

YMR000122

SHAFT, CONTROL

19

YMR000250

SPACER

23

YMR000251

BOLT, REVOL. LIMIT

24

YMR000252

BOLT, IDLE LIMIT

25

YMR000253

SPACER

30

YMR001123

SHAFT, GOVERNOR LEVER

31

YMR001124

TORQUE SPRING ASSY.

32

YMR000352

KIT, SHIM

46

YMR001125

SPRING

55

YMR000258

O-RING

56

YMR000838

RETAINER, SHAFT

57

YMR000259

SCREW

58

YMR000090

NUT

59

YMR000354

WASHER

60

YMR001022

WASHER

61

YMR001023

GASKET

62

YMR000852

WASHER

63

YMR000361

WASHER

64

YMR000598

PIN

65

YMR001020

PLUG

66

YMR001126

O-RING

67

YMR000752

BOLT PLATED

68

YMR000752

BOLT PLATED

69

YMR000752

BOLT PLATED

70

YMR000396

SCREW

71

YMR000397

SCREW

72

YMR000430

NUT

73

YMR000431

NUT

74

YMR000425

NUT

75

YMR000123

HANDLE

76

YMR000125

SPRING

77

YMR000489

SPRING

78

YMR001098

SOLENOID

79

YMR000427

CAP NUT

80

YMR000488

SCREW

81

YMR000567

ANGLEICH ASSY.
