Запчасти Komatsu PC10-7 МОТОР ПОВОРОТА(№-777) ПОВОРОТН. КРУГ И КОМПОНЕНТЫ

|1

20N-60-46500

MOTOR ASS'Y,SWING

|1

920N-60-46501

MOTOR ASS'Y,SWING

1

20N-60-73110

HOUSING,BEARING

2

20N-60-46600

GEAR ASS'Y,PINION

3

20N-60-46275

BEARING

4

20N-60-46630

SPACER

5

20N-60-46165

O-RING

6

20N-60-46115

RING,BACK UP

7

20N-60-46286

RING,RETAINER

8

20N-60-26295

RING

9

20N-60-46155

O-RING

10

01252-41240

BOLT

11

01602-21236

WASHER

12

20N-60-46255

BEARING

13

20N-60-16120

RING

14

20N-60-16240

PLATE,VALVE

15

20N-60-16170

RING

16

20M-60-26330

VALVE

17

20N-60-16250

PLATE

18

20N-60-16260

SPRING

19

20N-60-16190

SEAL,INNER

20

20N-60-16270

PIN

21

20N-60-16180

SEAL,OUTER

22

20N-60-46350

VALVE

23

20N-60-46365

GEROLER

|23

20N-60-46360

GEROLER

24

20N-60-16310

VALVE,DRIVE

25

20N-60-16160

RING

26

20N-60-16330

BALL

27

20N-60-16340

PLUG

28

20N-60-16220

O-RING

29

20N-60-16320

HOUSING

30

20N-60-16230

PLUG

31

20N-60-16210

O-RING

32

FF7822-61330

BOLT

33

20N-60-46315

FLANGE

34

20N-60-46145

O-RING
