Запчасти Komatsu PC09-1 ГИДРОМОЛОТ (ВНУТР. ЧАСТИ) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|$0

21S-970-3210

BREAKER ASS'Y,HYDRAULIC

1

22J-970-1290

END,FRONT

2

21S-970-2550

NIPPLE,GREASE

3

21S-970-2542

PIN,RETAINER

4

21S-970-2531

PIN

5

21S-970-2750

COLLAR

6

21S-970-2760

PIN

7

21S-970-2560

SPRING

8

21S-970-2570

ROLLER

9

21S-970-2580

BUSHING,CHISEL

10

21S-970-2590

BUSHING,CHISEL

11

22J-970-1280

CYLINDER

12

21S-970-2340

PLUG

13

21S-970-2450

PIN

14

21S-970-2470

PACKING

15

21S-970-2480

SEAL,DUST

16

22J-970-1260

BODY,VALVE

17

21S-970-2340

PLUG

18

21S-970-2430

O-RING

19

21S-970-2350

BOLT

20

21S-970-2520

NUT

21

21S-970-2510

WASHER

22

22J-970-1270

PISTON

23

21S-970-2410

TUBE,INNER

24

21S-970-2390

BALL,STEEL

25

21S-970-2380

SPRING

26

21S-970-2370

PLUG

27

21S-970-2360

VALVE,CONTROL

28

21S-970-2260

SHELL

29

21S-970-2270

RING,BACK-UP

30

21S-970-2280

O-RING

31

21S-970-2780

RING

32

21S-970-2290

BOLT

33

21S-970-2240

COVER

34

21S-970-2250

DIAPHRAGM

35

21S-970-2220

BOLT,CAP

36

21S-970-2230

WASHER,SEAL

37

21S-970-2210

CAP
