Запчасти Komatsu PC09-1 УПРАВЛЯЮЩ. КЛАПАН (-СЕКЦ.) (/) (ВНУТР. ЧАСТИ) (ISO SHIFT PATTERN) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|$0

21S-60-31402

VALVE ASS'Y

|$1

21S-60-31401

VALVE ASS'Y

|$3

NA371421266401

VALVE ASS'Y,ARM

1

BLOCK,XA

|$5

NA371421267301

SPOOL ASS'Y,ARM

2

SPOOL,ARM

3

NA401101010000

O-RING

4

NA440211010000

RING,BACK UP

5

NA371416994701

PLATE

6

NA371416994801

RETAINER

7

NA257417185601

SPRING

8

NA371420510501

BOLT

9

NA401101010000

O-RING

10

NA440211010000

RING,BACK UP

11

NA371416994701

PLATE

12

NA031110501064

SCREW

13

NA332090701014

VALVE

14

NA257417053001

SPRING

15

NA401100011010

O-RING

16

NA371416994501

SEAT

17

NA371416994601

COVER

18

NA002010504551

BOLT

19

NA401100014010

O-RING

20

NA251416995201

PLUG,PF3/8

21

NA374420244135

VALVE ASS'Y,OVER LOAD RELIEF

|$26

NA371421266501

VALVE ASS'Y,SWING

22

BLOCK,WC

|$28

NA371421267401

SPOOL ASS'Y,SWING

23

SPOOL,SWING

24

NA401101010000

O-RING

25

NA440211010000

RING,BACK UP

26

NA371416994701

PLATE

27

NA371416994801

RETAINER

28

NA257417185601

SPRING

29

NA371420510501

BOLT

30

NA401101010000

O-RING

31

NA440211010000

RING,BACK UP

32

NA371416994701

PLATE

33

NA031110501064

SCREW

34

NA332090701014

VALVE

35

NA257417053001

SPRING

36

NA401100011010

O-RING

37

NA371416994501

SEAT

38

NA371416994601

COVER

39

NA002010504551

BOLT

40

NA374421319403

VALVE ASS'Y

40

NA374421018409

VALVE ASS'Y

41

NA403100012710

O-RING

42

NA401100010010

O-RING
