Запчасти Komatsu PC09-1-B УПРАВЛЯЮЩ. КЛАПАН (9-СЕКЦИОНН.) (/) (ВНУТР. ЧАСТИ) (ФИКС. GAUGE СПЕЦ-Я.) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|1

21S-60-31101

VALVE ASS'Y

|1

NA371421266601

VALVE ASS'Y,L.H. TRAVEL

1

BLOCK,ZA

|2

NA371421267501

SPOOL ASS'Y,TRAVEL

2

SPOOL

3

NA401101010000

O-RING

4

NA440211010000

RING,BACK UP

5

NA371416994701

PLATE

6

NA371416994801

RETAINER

7

NA257417185601

SPRING

8

NA371420510501

BOLT

9

NA401101010000

O-RING

10

NA440211010000

RING,BACK UP

11

NA371416994701

PLATE

12

NA031110501064

SCREW

13

NA401100011010

O-RING

14

NA371416994501

SEAT

15

NA371416994601

COVER

16

NA002010504551

BOLT

|17

NA371421266801

VALVE ASS'Y,BLADE

17

BLOCK,ZH

|18

NA371421267601

SPOOL ASS'Y,BLADE

18

SPOOL,BLADE

19

NA401101010000

O-RING

20

NA440211010000

RING,BACK UP

21

NA371416994701

PLATE

22

NA371416994801

RETAINER

23

NA257417185601

SPRING

24

NA371420510501

BOLT

25

NA401101010000

O-RING

26

NA440211010000

RING,BACK UP

27

NA371416994701

PLATE

28

NA031110501064

SCREW

29

NA332090701014

VALVE

30

NA257417053001

SPRING

31

NA401100011010

O-RING

32

NA371416994501

SEAT

33

NA371416994601

COVER

34

NA002010504551

BOLT

35

NA403100012710

O-RING

36

NA401100010010

O-RING
