Запчасти Komatsu PC07-2 7-СЕКЦИОНН. УПРАВЛЯЮЩ. КЛАПАН (/) УПРАВЛ-Е РАБОЧИМ ОБОРУДОВАНИЕМ

\0

844020137

CONTROL VALVE, ASSY.

1

844200163

ELEMENT, EQUIPMENT

2

844200173

KIT, SPOOL GASKET

3

844200175

KIT, GASKET

4

845010257

SAFETY VALVE

5

844200174

KIT, GASKET

6

PLUG

7

844200169

SPOOL RETURN UNIT

8

844200170

SPRING

9

PLATE

10

844200155

ELEMENT, LEFT TRAVEL

11

844200173

KIT, SPOOL GASKET

12

844200175

KIT, GASKET

13

PLUG

14

844200169

SPOOL RETURN UNIT

15

844200170

SPRING

16

844200154

ELEMENT, BOOM

17

844200173

KIT, SPOOL GASKET

18

844200175

KIT, GASKET

19

844200171

SPOOL RETURN UNIT

20

844200172

SPRING

21

845010257

SAFETY VALVE

22

844200174

KIT, GASKET

23

844200185

PLUG

24

844200174

KIT, GASKET

25

845010260

VALVE

26

844200153

ELEMENT, INLET AND BUCKET

27

844200173

KIT, SPOOL GASKET

28

844200175

KIT, GASKET

29

844200171

SPOOL RETURN UNIT

30

844200172

SPRING

31

845010260

ANTICAVITATION VALVE

32

845010257

MAIN SAFETY VALVLE

33

844200174

KIT, GASKET
