Запчасти Komatsu PC07-2 7-СЕКЦИОНН. УПРАВЛЯЮЩ. КЛАПАН (/) УПРАВЛ-Е РАБОЧИМ ОБОРУДОВАНИЕМ

\0

844020137

CONTROL VALVE, ASSY.

1

844200167

KIT, TIE-ROD

2

844200164

ELEMENT, OUTLET

3

844200175

KIT, GASKET

4

845010257

MAIN SAFETY VALVLE

5

844200174

KIT, GASKET

6

844200159

ELEMENT, ARM

7

844200173

KIT, SPOOL GASKET

8

844200175

KIT, GASKET

9

844200171

SPOOL RETURN UNIT

10

844200172

SPRING

11

844200185

PLUG

12

844200174

KIT, GASKET

13

845010260

VALVE

14

845010257

SAFETY VALVE

15

844200174

KIT, GASKET

16

844200158

ELEMENT, SWING BOOM

17

844200173

KIT, SPOOL GASKET

18

844200175

KIT, GASKET

19

845010258

ANTICAVITATION VALVE

20

844200174

KIT, GASKET

21

845010260

VALVE

22

844200185

PLUG

23

844200174

KIT, GASKET

24

844200169

SPOOL RETURN UNIT

25

844200170

SPRING

26

844200157

ELEMENT, RIGHT TRAVEL

27

844200173

KIT, SPOOL GASKET

28

844200175

KIT, GASKET

29

PLUG

30

844200169

SPOOL RETURN UNIT

31

844200170

SPRING

32

844200178

KIT, GASKET, ASSY.
