Запчасти Komatsu PC07-2 ТОПЛИВН. ФОРСУНКА И СЛИВНАЯ ТРУБКА ДВИГАТЕЛЬ

1

YMR000762

INJECTION PUMP

3

YMR000763

PLUNGER W/BARREL

6

YMR000764

RETAINER

7

YMR000765

RETAINER

8

YMR000766

SPRING

9

YMR000767

SHIM

10

YMR000768

VALVE W/SEAT, DELIV.

13

YMR000769

SPRING

14

YMR000770

HOLDER, DELIVERY VALVE

15

YMR000771

GASKET

16

YMR000772

O-RING

17

YMR000773

GUIDE

18

YMR000774

PIN

19

YMR000775

RACK

20

YMR000776

PINION

21

YMR000777

RETAINER, RACK

22

YMR000778

PLATE

23

YMR000779

SCREW

24

YMR000780

PIN

25

YMR000781

PIN

26

YMR000782

TAPPET, ASSY.

31

YMR000783

WASHER

32

YMR000784

SPRING WASHER

33

YMR000785

SCREW

34

YMR000786

SCREW

35

YMR000787

OIL PRESSURE VALVE, ASSY.

36

YMR000788

FUEL INJECTION NOZZLE, ASSY.

39

YMR000789

NUT

40

YMR000790

HOLDER, VALVE W/CASE

41

YMR000791

SPRING

42

YMR000015

SEAT, NOZZLE SPRING

43

YMR000792

SPACER, VALVE STOP

44

YMR000018

SHIM

45

YMR000230

O-RING

46

YMR000198

RETAINER, PIPE

49

YMR000199

SCREW

50

YMR000793

INJECTION PIPE N. 1

51

YMR000794

INJECTION PIPE N. 2

52

YMR000795

INJECTION PIPE N. 3

53

YMR000093

CLAMP

54

YMR000796

PIPE, FUEL OIL

55

YMR000797

PIPE ASSY., FUEL OVER

56

YMR000077

CLAMP

57

YMR000798

JOINT

58

YMR000799

JOINT

59

YMR000800

PIPE, FUEL RETURN

60

YMR000801

PIPE, FUEL RETURN

61

YMR000802

JOINT

62

YMR000803

NUT

63

YMR000089

BOLT, PIPE JOINT

64

YMR000804

GASKET

65

YMR000805

GASKET
