Запчасти Komatsu PC07-2 ГИДР. НАСОС. (/) (ДЛЯ ЯПОН.) (ВНУТР. ЧАСТИ)(№-) ГИДРАВЛИКА

|1

705-41-08180

PUMP ASS'Y

|1

705-41-04140

PUMP ASS'Y (SBR6A),(SBR6A)

1

705-40-80511

BRACKET

|1

705-40-80620

BUSHING,PLANE (DRIVE SIDE)

|1

705-40-80610

BUSHING,PLANE (DRIVEN SIDE)

2

705-41-18010

CASE,GEAR

3

705-41-80310

CARRIER

|3

705-40-80610

BUSHING,PLANE (DRIVE SIDE)

|3

705-40-80620

BUSHING,PLANE (DRIVEN SIDE)

4

705-41-18460

GEAR,DRIVE

5

705-40-18510

GEAR,DRIVEN

6

705-40-83720

PLATE,SIDE

7

705-40-80760

SEAL,RING

8

705-67-01910

PIN,DOWEL

9

705-67-01230

PIN

10

705-17-02680

BOLT,RING

11

01643-51232

WASHER

12

705-67-01330

COUPLING ASS'Y

13

705-40-80660

SEAL

14

705-41-80750

BOLT

15

01643-50823

WASHER

16

705-40-80941

PLATE

17

07000-02021

O-RING

18

705-41-80750

BOLT

19

01643-50823

WASHER
