Запчасти Komatsu PC05-7 ГОЛОВКА ЦИЛИНДРОВ ДВИГАТЕЛЬ

Схема запчастей Komatsu PC05-7 - ГОЛОВКА ЦИЛИНДРОВ ДВИГАТЕЛЬ
43
A
46
52
53
54
51
48
42
47
49
50
40
38
41
24
23
56
28
33
55
36
27
55
29
34
32
55
37
30
39
8
9
18
15
14
2
1
13
21
20
17
3
21
16
10
22
10
19
12
11

Артикул

Название

Примечание

Количество

\0

871070007

ENGINE, ASSY.

1

YMR000652

LIFTER

2

YMR000395

SCREW

3

YMR000653

CYLINDER HEAD

8

YMR000071

PLUG

9

YMR000654

PLUG

10

YMR000437

PLUG

11

YMR000655

VALVE, INLET

12

YMR000656

VALVE EXHAUST

13

YMR000657

SPRING, VALVE

14

YMR000658

RETAINER, SPRING

15

YMR000659

COTTER

16

YMR000660

SEAL, VALVE STEM

17

YMR000661

SEAL, VALVE STEM

18

YMR000662

CAP VALVE

19

YMR000365

PEG

20

YMR000663

PROTECTION, NOZZLE

21

YMR000664

GASKET

22

YMR000665

GUIDE VALVE

23

YMR000666

ROCKER SHAFT

24

YMR000667

SHAFT

27

YMR000668

SUPPORT

28

YMR000669

SPRING

29

YMR000670

ROCKER SHAFT

30

YMR000671

TAPPET

32

YMR000430

NUT

33

YMR000672

ROCKER SHAFT

34

YMR000671

TAPPET

36

YMR000430

NUT

37

YMR000674

RING, SNAP

38

YMR000675

SCREW

39

YMR000676

STUD

40

YMR000407

SCREW

41

YMR000425

NUT

42

YMR000677

HEAD COVER, ASSY.

43

YMR000078

OIL PLUG

46

YMR000384

O-RING

47

YMR000678

COVER

48

YMR000679

GASKET

49

YMR000680

SPRING WASHER

50

YMR000681

SCREW

51

YMR000606

GASKET, BONNET

52

YMR000080

KNOB

53

YMR000382

O-RING

54

YMR000682

PIPE

55

YMR000683

PLUG

56

YMR000684

CONNECTOR

Выбрано товаров: 47
