Запчасти Komatsu PC05-7 ТОПЛИВН. ФИЛЬТР. И ТРУБЫ ДВИГАТЕЛЬ

Схема запчастей Komatsu PC05-7 - ТОПЛИВН. ФИЛЬТР. И ТРУБЫ ДВИГАТЕЛЬ
26
22
25
17
16
37
46
34
33
43
A
21
23
20
19
15
29
28
24
29
27
31
1
18
13
32
2
14
3
4
35
8
42
10
41
45
5
44
39
6
36
7
40
38

Артикул

Название

Примечание

Количество

1

YMR000806

FILTER

2

YMR000007

VALVE, TAPER

3

YMR000008

SPRING

4

YMR000807

LINK

5

YMR000808

CUP, STRAINER

6

YMR000003

GASKET

7

YMR000012

RING, NUT

8

YMR000809

SPRING

10

YMR000603

ELEMENT

13

YMR000010

SCREW

14

YMR000385

O-RING

15

YMR000810

FILTER SUPPORT

16

YMR000077

CLAMP

17

YMR000200

CAP

18

YMR000392

BOLT

19

YMR000401

BOLT

20

YMR000811

FUEL OIL PIPE, ASSY.

21

YMR000001

JOINT

22

YMR000093

CLAMP

23

YMR000812

PIPE

24

YMR000093

CLAMP

25

YMR000011

GASKET

26

YMR000813

BOLT, PIPE JOINT

27

YMR000814

FUEL FEED PUMP, ASSY.

28

YMR000815

BEND, ASSY.

29

YMR000093

CLAMP

31

YMR000816

JOINT

32

YMR000280

WATER SEPARATOR

33

YMR000007

VALVE, TAPER

34

YMR000008

SPRING

35

YMR000009

HANDLE, COCK

36

YMR000076

BOWL, FUEL STRAINER

37

YMR000003

GASKET

38

YMR000012

RING, NUT

39

YMR000062

SPRING

40

YMR000063

FLOAT

41

YMR000817

BODY, STRAINER

42

YMR000002

PLUG

43

YMR000010

SCREW

44

YMR000341

SCREEN

45

YMR000376

GASKET

46

YMR000385

O-RING

Выбрано товаров: 42
