Запчасти Komatsu PC05-7 ГИДРАВЛ УПРАВЛЯЮЩ. КЛАПАН (9-СЕКЦИОНН.) (/) (ВНУТР. ЧАСТИ)(№7-) ГИДРАВЛИКА

|1

724-00-17000

VALVE ASS'Y

|1

724-00-41760

BLOCK AND SPOOL KIT

1

BLOCK

2

SPOOL,BOOM

|3

724-00-41750

BLOCK AND SPOOL KIT

3

BLOCK

4

SPOOL,BOOM SWING

|5

724-00-33950

SPOOL KIT

5

BLOCK

6

SPOOL,SERVICE

7

724-00-31340

RETAINER

8

724-00-31350

SPRING

9

724-00-31330

COVER

10

724-00-31360

O-RING

11

724-00-30545

BOLT

12

724-00-31760

SEAL,OIL

13

724-00-31720

PLATE

14

724-00-31730

RETAINER

15

724-00-31750

SPRING

16

724-00-31740

BOLT

17

724-00-31710

COVER

18

01252-30510

BOLT

19

01252-30540

BOLT

20

724-00-81110

SLEEVE

21

07012-11623

O-RING

22

724-00-81130

BALL

23

724-00-81120

SPRING

24

724-00-81330

PLUG

25

07002-11623

O-RING

26

724-00-81340

PLUG

27

07002-11423

O-RING

28

724-00-81320

PLUG

29

07002-11423

O-RING

30

724-00-51150

O-RING

31

724-00-81210

SLEEVE

32

07002-11223

O-RING

33

724-00-81230

BALL

34

724-00-81220

SPRING

35

724-00-31270

TUBE

36

724-00-81510

O-RING

37

07000-12011

O-RING

38

724-00-62000

VALVE ASS'Y
