Запчасти Komatsu PC03-2 ГУСЕНИЧНАЯ РАМА (ДЛЯ ALTERABLE GAUGE СПЕЦ-Я.) ХОДОВАЯ

1

21S-35-27111

FRAME,TRACK

2

21S-35-27121

FRAME,L.H.

3

21S-35-27131

FRAME,R.H.

|4

21S-35-27910

LINK ASS'Y,FRONT

4

LINK,FRONT

5

20A-70-11720

BUSHING

6

20A-70-12211

SEAL,DUST

7

21S-35-27290

SPACER

|8

21S-35-27930

LINK ASS'Y,REAR¤ L.H.

8

LINK,REAR¤ L.H.

5

20A-70-11720

BUSHING

6

20A-70-12211

SEAL,DUST

7

21S-35-27290

SPACER

|9

21S-35-27940

LINK ASS'Y,REAR¤ R.H.

9

LINK,REAR¤ R.H.

5

20A-70-11720

BUSHING

6

20A-70-12211

SEAL,DUST

7

21S-35-27290

SPACER

10

21R-70-11380

SPACER¤ 1.0MM

11

21S-35-27220

PIN

12

04082-00110

LOCK

13

01010-51025

BOLT

14

01643-31032

WASHER

15

21R-70-11380

SPACER¤ 1.0MM

16

21S-35-27250

PIN

17

01010-51020

BOLT

18

01643-31032

WASHER

19

21S-35-27261

LINK

20

20A-70-11860

BUSHING

21

20A-70-12211

SEAL

22

21R-70-11380

SPACER¤ 1.0MM

23

21S-35-27270

PIN

24

01010-51020

BOLT

25

01643-31032

WASHER

26

20A-70-11420

PIN

27

21S-35-27250

PIN

28

01010-51020

BOLT

29

01643-31032

WASHER

30

21S-35-27281

COVER

31

01435-00816

BOLT
