Запчасти Komatsu PC03-2-A ГИДРОМОЛОТ (ВНУТР. ЧАСТИ) РАБОЧЕЕ ОБОРУДОВАНИЕ

|1

21S-970-2111

BREAKER,HYDRAULIC

1

21S-970-2490

END,FRONT

2

21S-970-2550

NIPPLE,GREASE

3

20A-70-11720

BUSHING

4

20A-70-12211

SEAL,DUST

5

21S-970-2541

PIN,RETAINER

6

21S-970-2740

WASHER

7

21S-970-2770

BOLT

8

21S-970-2531

PIN

9

21S-970-2750

COLLAR

10

21S-970-2760

PIN

11

21S-970-2560

SPRING

12

21S-970-2570

ROLLER

13

21S-970-2590

BUSHING,CHISEL

14

21S-970-2580

BUSHING,CHISEL

15

21S-970-2460

CYLINDER

16

21S-970-2340

PLUG

17

21S-970-2450

PIN

18

21S-970-2470

PACKING

19

21S-970-2480

SEAL,DUST

20

21S-970-2310

BODY,VALVE

21

21S-970-2340

PLUG

22

21S-970-2430

O-RING

23

21S-970-2350

BOLT

24

21S-970-2520

NUT

25

21S-970-2510

WASHER

26

21S-970-2420

PISTON

27

21S-970-2410

TUBE,INNER

28

21S-970-2390

BALL,STEEL

29

21S-970-2380

SPRING

30

21S-970-2370

PLUG

31

21S-970-2360

VALVE,CONTROL

32

21S-970-2260

SHELL

33

21S-970-2270

RING,BACK-UP

34

21S-970-2280

O-RING

35

21S-970-2290

BOLT

36

21S-970-2240

COVER

37

21S-970-2250

DIAPHRAGM

38

21S-970-2220

BOLT,CAP

39

21S-970-2230

WASHER,SEAL

40

21S-970-2210

CAP
