Запчасти Komatsu PC01-1 УПРАВЛЯЮЩ. КЛАПАН (/) (9-СЕКЦИОНН.) (ВНУТР. ЧАСТИ)(№77-) УПРАВЛ-Е РАБОЧИМ ОБОРУДОВАНИЕМ

|$7

21A-60-12100

VALVE ASS'Y

|$9

NA371421391001

VALVE ASS'Y,R.H. TRAVEL

1

BLOCK,ZA

|$11

NA371421390901

SPOOL ASS'Y,TRAVEL

2

SPOOL,TRAVEL

3

NA401101010000

O-RING

4

NA440211010000

RING,BACK UP

5

NA371416994701

PLATE

6

NA371416994801

RETAINER

7

NA257417185601

SPRING

8

NA371420510501

BOLT

9

NA401101010000

O-RING

10

NA440211010000

RING,BACK UP

11

NA371416994701

PLATE

12

NA031110501064

SCREW

13

NA332090701014

VALVE

14

NA257417053001

SPRING

15

NA401100011010

O-RING

16

NA371416994501

SEAT

17

NA371416994601

COVER

18

NA002010504551

BOLT

19

NA401100014010

O-RING

20

NA251416995201

PLUG,PF3/8

21

NA37442024411X

VALVE ASS'Y,OVER LOAD RELIEF

|$32

NA371421267101

VALVE ASS'Y,BOOM

22

BLOCK,YC

|$34

NA371421271301

SPOOL ASS'Y,BOOM

23

SPOOL,BOOM

24

NA401101010000

O-RING

25

NA440211010000

RING,BACK UP

26

NA371416994701

PLATE

27

NA371416994801

RETAINER

28

NA257417185601

SPRING

29

NA371420510501

BOLT

30

NA401101010000

O-RING

31

NA440211010000

RING,BACK UP

32

NA371416994701

PLATE

33

NA031110501064

SCREW

34

NA332090701014

VALVE

35

NA257417053001

SPRING

36

NA401100011010

O-RING

37

NA371416994501

SEAT

38

NA371416994601

COVER

39

NA002010504551

BOLT

40

NA374420586907

VALVE ASS'Y,BUCKET

|$53

NA371421267201

VALVE ASS'Y,BUCKET

41

BLOCK,ZA

|$55

NA371421268001

SPOOL ASS'Y,BUCKET

42

SPOOL,BUCKET

43

NA401101010000

O-RING

44

NA440211010000

RING,BACK UP

45

NA371416994701

PLATE

46

NA371416994801

RETAINER

47

NA257417185601

SPRING

48

NA371420510501

BOLT

49

NA401101010000

O-RING

50

NA440211010000

RING,BACK UP

51

NA371416994701

PLATE

52

NA031110501064

SCREW

53

NA332090701014

VALVE

54

NA257417053001

SPRING

55

NA401100011010

O-RING

56

NA371416994501

SEAT

57

NA371416994601

COVER

58

NA002010504551

BOLT

59

NA403100012710

O-RING

60

NA401100010010

O-RING
