Запчасти Komatsu PC01-1 УПРАВЛЯЮЩ. КЛАПАН (/) (9-СЕКЦИОНН.) (ВНУТР. ЧАСТИ)(№77-) УПРАВЛ-Е РАБОЧИМ ОБОРУДОВАНИЕМ

|$7

21A-60-12100

VALVE ASS'Y

|$9

NA371421390101

VALVE ASS'Y,ARM

1

BLOCK,XA

|$11

NA371421390901

SPOOL ASS'Y,ARM

2

SPOOL,ARM

3

NA401101010000

O-RING

4

NA440211010000

RING,BACK UP

5

NA371416994701

PLATE

6

NA371416994801

RETAINER

7

NA257417185601

SPRING

8

NA371420510501

BOLT

9

NA401101010000

O-RING

10

NA440211010000

RING,BACK UP

11

NA371416994701

PLATE

12

NA031110501064

SCREW

13

NA332090701014

VALVE

14

NA257417053001

SPRING

15

NA401100011010

O-RING

16

NA371416994501

SEAT

17

NA371416994601

COVER

18

NA002010504551

BOLT

|$29

NA371421390301

VALVE ASS'Y,SWING

19

BLOCK,WC

|$31

NA371421390201

SPOOL ASS'Y,SWING

20

SPOOL,SWING

21

NA401101010000

O-RING

22

NA440211010000

RING,BACK UP

23

NA371416994701

PLATE

24

NA371416994801

RETAINER

25

NA257417185601

SPRING

26

NA371420510501

BOLT

27

NA401101010000

O-RING

28

NA440211010000

RING,BACK UP

29

NA371416994701

PLATE

30

NA031110501064

SCREW

31

NA332090701014

VALVE

32

NA257417053001

SPRING

33

NA401100011010

O-RING

34

NA371416994501

SEAT

35

NA371416994601

COVER

36

NA002010504551

BOLT

37

NA401100014010

O-RING

38

NA251416995201

PLUG,PF3/8

39

NA37442024411X

VALVE ASS'Y,OVER LOAD RELIEF

40

NA403100012710

O-RING

41

NA401100010010

O-RING
