Запчасти Komatsu PC01-1 ГИДРАВЛ УПРАВЛЯЮЩ. КЛАПАН (/) (8-СЕКЦИОНН.) УПРАВЛ-Е РАБОЧИМ ОБОРУДОВАНИЕМ

|$2

724-00-11000

VALVE ASS'Y

1

724-00-31310

BLOCK

2

BLOCK (K5)

3

BLOCK (K6)

4

BLOCK (K7)

5

BLOCK (K8)

6

724-00-31150

BLOCK

7

724-00-81510

O-RING

8

07000-12011

O-RING

9

724-00-31220

PISTON

10

724-00-31210

PLATE

11

SPOOL,BLADE (K5)

12

SPOOL,R.H. TRAVEL (K6)

13

SPOOL,BOOM (K7)

14

SPOOL,BUCKET (K8)

15

724-00-31760

SEAL,OIL

16

724-00-31720

PLATE

17

724-00-31730

RETAINER

18

724-00-31750

SPRING

19

724-00-31740

BOLT

20

724-00-31710

COVER

21

01252-30510

BOLT

22

01252-30540

BOLT

23

724-00-81130

BALL

24

724-00-81120

SPRING

25

724-00-81110

SLEEVE

26

07002-11623

O-RING

27

724-00-81230

BALL

28

724-00-81220

SPRING

29

724-00-81210

SLEEVE

30

07002-11223

O-RING

31

724-00-81320

PLUG

32

07002-11423

O-RING

33

724-00-51150

O-RING

34

724-00-81330

PLUG

35

07002-11623

O-RING

36

724-00-81310

PLUG

37

07002-11223

O-RING

38

07040-11409

PLUG

39

07002-01423

O-RING

40

724-00-51000

VALVE ASS'Y,MAIN RELIEF

41

724-00-61000

VALVE ASS'Y,SAFETY

K5

724-00-31950

SPOOL KIT,BLADE

2

BLOCK

11

SPOOL

K6

724-00-31960

SPOOL KIT,R.H. TRAVEL

3

BLOCK

12

SPOOL

K7

724-00-31970

SPOOL KIT,BOOM

4

BLOCK

13

SPOOL

K8

724-00-31980

SPOOL KIT,BUCKET

5

BLOCK

14

SPOOL
