Запчасти Komatsu MX202 КАБИНА (ТРУБЫ ЛЕВ.) КАБИНА ОПЕРАТОРА И СИСТЕМА УПРАВЛЕНИЯ

1

460-620

PILOT VALVE,(SEE FIG.Y1670-11A0)

2

107-962

BOLT

3

455-225

WASHER

4

450-670

PLUG

5

453-705

O-RING

6

456-652

BOLT

7

453-705

O-RING

8

457-935

HOSE,WHITE

|8

458-419

O-RING

|8

450-128

BAND¤ WHITE

9

457-935

HOSE,BROWN

|9

458-419

O-RING

|9

450-124

BAND¤ BROWN

10

457-894

HOSE,GREEN

|10

458-419

O-RING

|10

450-125

BAND¤ GREEN

11

457-894

HOSE,ORANGE

|11

458-419

O-RING

|11

450-126

BAND¤ ORANGE

12

457-880

HOSE,GREEN¤ RED

|12

450-125

BAND¤ GREEN

|12

450-127

BAND¤ RED

13

457-879

HOSE,BLUE¤ WHITE

|13

450-123

BAND¤ BLUE

|13

450-128

BAND¤ WHITE

14

450-105

BAND

15

458-229

ELBOW

16

457-762

ELBOW

17

453-695

O-RING

18

453-688

O-RING

19

457-833

GROMMET

20

451-428

CLIP

21

457-653

CLIP

22

105-274

BOLT

23

455-220

WASHER

24

458-684

SEAT

25

450-130

BAND

26

451-314

CLIP

27

105-274

BOLT

28

455-220

WASHER

29

456-290

SHEET

30

450-110

BAND
