Запчасти Komatsu MX182 ТОПЛ. БАК И ТОПЛИВОПРОВОД ТОПЛИВН. БАК. AND КОМПОНЕНТЫ

1

460-952

TANK,FUEL

2

458-839

STRAINER

|3

456-989

CAP ASS'Y

4

454-007

PACKING

5

452-363

ELEMENT

6

460-391

GAUGE

7

452-435

FLOAT

8

451-508

CLIP

9

460-269

COVER

10

460-974

TUBE

11

460-967

TUBE

12

451-433

CLIP

13

451-434

CLIP

14

460-392

GAUGE,FUEL

15

454-004

PACKING

16

455-243

SCREW

17

460-186

BRACKET

18

105-274

BOLT

19

455-220

WASHER

20

456-318

SHEET

21

460-311

CUSHION

22

460-309

CUSHION

23

451-968

CUSHION

24

460-229

CAP

25

453-706

O-RING

26

460-478

HOSE ASS'Y

27

460-262

CONDUIT

28

460-475

HOSE ASS'Y

29

460-477

HOSE ASS'Y

30

451-435

CLIP

31

451-508

CLIP

32

460-197

BRACKET

33

105-274

BOLT

34

455-220

WASHER

35

460-451

HOSE

36

460-251

CLIP

37

458-257

VALVE

38

457-766

ELBOW

39

107-972

BOLT

40

455-225

WASHER

41

451-412

CLIP

42

105-274

BOLT

43

455-220

WASHER

44

107-955

BOLT

45

455-226

WASHER

46

451-413

CLIP

47

107-965

BOLT

48

455-225

WASHER
