Запчасти Komatsu MX09 ГИДРОМОЛОТ (ВНУТР. ЧАСТИ) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|1

455-385

BREAKER ASS'Y,HYDRAULIC

1

455-450

END,FRONT

2

453-430

NIPPLE,GREASE

3

454-170

PIN,RETAINER

4

454-169

PIN

5

451-535

COLLAR

6

454-171

PIN

7

453-732

SPRING

8

451-982

ROLLER

9

451-068

BUSHING,CHISEL

10

451-069

BUSHING,CHISEL

11

455-433

CYLINDER

12

450-665

PLUG

13

454-168

PIN

14

454-008

PACKING

15

456-041

SEAL,DUST

16

455-661

BODY,VALVE

17

450-665

PLUG

18

453-580

O-RING

19

456-670

BOLT

20

454-964

NUT

21

455-164

WASHER

22

455-533

PISTON

23

458-118

TUBE,INNER

24

450-087

BALL,STEEL

25

453-731

SPRING

26

450-666

PLUG

27

451-620

VALVE,CONTROL

28

457-413

SHELL

29

450-960

RING,BACK-UP

30

453-579

O-RING

31

450-961

RING

32

456-669

BOLT

33

451-712

COVER

34

452-156

DIAPHRAGM

35

456-668

BOLT,CAP

36

455-163

WASHER,SEAL

37

451-194

CAP
