Запчасти Komatsu MX09 УПРАВЛЯЮЩ. КЛАПАН (-СЕКЦ.) (/) (ВНУТР. ЧАСТИ) (ISO SHIFT PATTERN) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|1

456-841

VALVE ASS'Y

|1

458-304

VALVE ASS'Y

|1

458-356

VALVE ASS'Y,L.H. TRAVEL

|2

457-626

SPOOL ASS'Y,TRAVEL

3

453-637

O-RING

4

455-013

RING,BACK UP

5

454-731

PLATE

6

450-927

RETAINER

7

456-835

SPRING

|7

453-813

SPRING

8

456-688

BOLT

9

453-637

O-RING

10

455-013

RING,BACK UP

11

454-731

PLATE

12

455-307

SCREW

13

453-635

O-RING

14

456-153

SEAT

15

451-837

COVER

16

456-686

BOLT

|17

458-357

VALVE ASS'Y,BLADE

|18

457-627

SPOOL ASS'Y,BLADE

19

453-637

O-RING

20

455-013

RING,BACK UP

21

454-731

PLATE

22

450-927

RETAINER

23

453-813

SPRING

24

456-688

BOLT

25

453-637

O-RING

26

455-013

RING,BACK UP

27

454-731

PLATE

28

455-307

SCREW

29

458-283

VALVE

30

453-812

SPRING

31

453-635

O-RING

32

456-153

SEAT

33

451-837

COVER

34

456-686

BOLT

35

453-638

O-RING

36

453-634

O-RING
