Запчасти Komatsu HB215LC-1M0 СТРЕЛА, РУКОЯТЬ ANTI-DROP КЛАПАН (№-) СТРЕЛА, 7MM УСИЛ. ТИП, -НАВЕСН. ОБОРУД, PROVISION ДЛЯ БЫСТРОСЪЕМН. МЕХ-М

|$0

702-21-08860

Valve, Pilot

1

Body, Valve

2

Spool

3

702-21-38510

Case

4

Retainer, T=2.0mm

4

Retainer, T=1.7mm

4

Retainer, T=2.3mm

5

702-21-38741

Plate

6

702-21-38440

Spring

7

Spring

8

702-21-38460

O-ring

9

702-21-38470

O-ring

10

702-21-38480

Plug

11

01252-60825

Bolt, Hexagon Socket Head

12

01252-60835

Bolt, Hexagon Socket Head

13

01252-60625

Bolt, Hexagon Socket Head

14

01641-20608

Washer

15

07000-12021

O-ring

16

702-21-39690

Valve

17

709-75-92220

Spring

18

700-93-11320

O-ring

19

700-93-11330

Ring, Back-up

20

723-90-66900

Valve, Relief

21

700-80-64220

Ring, Back-up

22

700-22-11410

O-ring

23

709-25-11390

O-ring
