Запчасти Komatsu HB215LC-1M0 СТРЕЛА, РУКОЯТЬ И ЦИЛИНДР КОВША ТРУБЫ (№-) СТРЕЛА, 7MM УСИЛ. ТИП, ЧАС. СМАЗКА INTERVAL

1

2A5-62-13181

Tube

2

07371-30640

Flange, Split

3

07372-21035

Bolt

4

01643-51032

Washer

5

2A5-62-13191

Tube

6

07371-31049

Flange, Split

7

07372-21035

Bolt

8

01643-51032

Washer

9

207-62-31340

Clamp

10

20Y-62-13720

Clamp

11

207-62-54780

Clamp

12

205-62-73431

Seat

13

20Y-62-13761

Seat

14

20Y-62-13450

Plate

15

2A5-62-19710

Plate

16

01010-81230

Bolt

17

07085-006A7

Hose, Flange Type

18

07000-13025

O-ring

19

07371-30640

Flange, Split

20

07372-21035

Bolt

21

01643-51032

Washer

22

20Y-62-53750

Hose

23

07000-13032

O-ring

24

07371-31049

Flange, Split

25

07372-21035

Bolt

26

01643-51032

Washer

27

2A5-62-13211

Tube

28

2A5-62-13171

Tube

29

07371-30640

Flange, Split

30

07371-31049

Flange, Split

31

07372-21035

Bolt

32

01643-51032

Washer

33

20Y-62-13710

Clamp

34

20Y-62-13190

Clamp

35

20Y-62-13761

Seat

36

205-62-73431

Seat

37

20Y-62-13450

Plate

38

01010-81230

Bolt

39

2A5-62-13221

Tube

40

20Y-62-52661

Tube

41

07000-13030

O-ring

42

07000-13035

O-ring

43

07372-21035

Bolt

44

01643-51032

Washer

45

07372-21040

Bolt

46

01643-51032

Washer

47

20Y-62-13650

Clamp

48

207-62-31330

Clamp

49

20Y-62-13180

Clamp

50

207-62-52350

Clamp

51

20Y-62-13761

Seat

52

205-62-73431

Seat

53

20Y-62-13450

Plate

54

01010-81230

Bolt
