Запчасти Komatsu HB215LC-1M0 СИСТЕМА ОХЛАЖДЕНИЯ, КОЖУХ (№-) СИСТЕМА ОХЛАЖДЕНИЯ

1

20Y-979-6271

Bracket

2

01010-80612

Bolt

2

01010-80616

Bolt

3

01643-30623

Washer

4

20Y-979-6191

Sensor

5

205-03-37451

Shroud

6

01010-81020

Bolt

7

01643-31032

Washer

7

205-03-37531

Cover Assembly

8

Cover

9

205-03-37551

Sheet

10

205-03-37941

Sheet

11

205-03-37950

Sheet

12

205-03-37961

Sheet

13

205-03-37971

Sheet

14

01010-81020

Bolt

15

01643-31032

Washer

16

205-03-37571

Cover

17

01010-81020

Bolt

18

01643-31032

Washer

18

205-03-37211

Cover Assembly

19

Cover

20

205-03-37591

Sheet

21

01010-81020

Bolt

22

01643-31032

Washer

22

205-03-37231

Cover Assembly

23

Cover

24

205-03-37581

Sheet

25

01010-81020

Bolt

26

01643-31032

Washer

26

205-03-37271

Cover Assembly

27

Cover

28

205-03-37991

Sheet

29

01010-81020

Bolt

30

01643-31032

Washer

31

205-03-37651

Sheet

32

205-03-33940

Sheet

33

22U-03-31170

Shroud

34

203-54-56970

Washer

35

01010-81025

Bolt
