Запчасти Komatsu HB215LC-1M0 НАВЕСН. ОБОРУД ТРУБЫ, ОСНОВН. ТРУБЫ, ПРАВ. (№-) НАВЕСН. ОБОРУД ТРУБЫ, PROVISION ДЛЯ БЫСТРОСЪЕМН. МЕХ-М

1

01010-81040

Bolt

2

01643-31032

Washer

3

205-62-34830

Bracket

4

07371-31049

Flange, Split

5

07372-21035

Bolt

6

01643-51032

Washer

7

07371-51260

Flange, Split

8

01010-81245

Bolt

9

01643-31232

Washer

10

20Y-62-43460

Nipple

11

02896-11008

O-ring

12

07002-12034

O-ring

13

11Y-62-12160

Elbow

14

02896-11008

O-ring

15

07002-11423

O-ring

|$15

20Y-970-6450

Accumulator Assembly

16

Shell

16

NFEB3401 A1

Bleeder Assembly

17

NFEB3026 A1

Bleeder

18

NFEB4475 Z0

Core

19

Nut

20

Cap

21

NFEB0427 Z0

Body Assembly

22

NFEB4477 Z0

Ring

23

O-ring

24

Ring, Back-up

25

Ring

26

Plate

27

205-970-5560

O-ring

28

Bushing

29

20Y-62-43290

Elbow

30

07002-12434

O-ring

31

20Y-62-43280

Bracket

32

01010-81295

Bolt

33

01643-31232

Washer

34

175-61-51750

Plate

35

01010-81225

Bolt

36

01643-31232

Washer

37

01010-81285

Bolt

38

01643-31232

Washer

39

07097-01005

Hose, Flange Type

40

07000-13032

O-ring

41

07371-31049

Flange, Split

42

07372-21035

Bolt

43

01643-51032

Washer

44

07099-21217

Hose, Flange Type

45

07000-13038

O-ring

46

07371-51260

Flange, Split

47

01010-81245

Bolt

48

01643-31232

Washer
