Запчасти Komatsu HB215LC-1M0 ANTI-DROP КЛАПАН, РУКОЯТЬ ANTI-DROP КЛАПАН ТРУБЫ (/) (№-) ANTI-DROP КЛАПАН, СТРЕЛА И РУКОЯТЬ ANTI-DROP КЛАПАН, СИГНАЛИЗ. ПЕРЕГРУЗКИ

1

2A5-62-18980

Joint

2

2A5-62-18971

Joint

3

01010-81235

Bolt

4

01643-31232

Washer

5

20Y-62-42890

Elbow

6

07002-12034

O-ring

7

02896-11012

O-ring

8

11Y-62-12160

Elbow

9

07002-11423

O-ring

10

02896-11008

O-ring

11

02781-00516

Union

12

07002-12034

O-ring

13

02896-11015

O-ring

14

02781-0021D

Union

15

07002-11423

O-ring

16

02896-11008

O-ring

17

2A5-62-18980

Joint

18

01010-81235

Bolt

19

01643-31232

Washer

20

11Y-62-12160

Elbow

21

07002-11423

O-ring

22

02896-11008

O-ring

23

02781-0021D

Union

24

07002-11423

O-ring

25

02896-11008

O-ring

26

2A5-62-16130

Hose

27

2A5-62-16140

Hose

28

20Y-62-22850

Band, Green

29

2A5-62-18932

Hose

30

20Y-62-22790

Band, Red

31

02776-004A4

Hose

32

2A5-62-16110

Hose

33

20Y-62-22850

Band, Green

34

2A5-62-18883

Hose

35

20Y-62-22790

Band, Red

36

134-03-61410

Band
