Запчасти Komatsu HB215LC-1M0 ГИДР. БАК. (№-) ГИДР. БАК., -ДОПОЛН. АКТУАТОР ТРУБЫ, АККУМУЛЯТОР, СТРЕЛА ANTI-DROP КЛАПАН

1

20Y-60-42111

Tank

2

203-60-31100

Elbow Assembly

3

203-60-31160

Tube

4

07044-12412

Plug

5

07002-12434

O-ring

6

02781-00628

Union

7

02896-11018

O-ring

8

07002-12434

O-ring

9

02782-10311

Elbow

10

02896-11009

O-ring

11

07002-11423

O-ring

12

20Y-62-45690

Tee

13

02896-11009

O-ring

14

02896-11008

O-ring

15

07002-12034

O-ring

16

207-60-71183

Element

17

20Y-60-31140

Strainer

18

20Y-60-31450

Valve Assembly

19

20Y-60-21240

Spring

20

207-60-77131

Cover

21

07000-15195

O-ring

22

01010-81225

Bolt

23

01643-31232

Washer

|$23

20Y-60-31171

Strainer Assembly

24

207-60-61150

Rod Assembly

25

20Y-60-21320

Holder

26

12R-60-11230

Spring

27

22B-60-11160

Strainer

28

20Y-60-42143

Cover

29

07000-15160

O-ring

30

01010-81225

Bolt

31

01643-31232

Washer

32

20Y-60-42220

Cap Assembly

33

20Y-60-42210

Filler Neck

34

20Y-60-21340

Gasket

35

01252-70516

Bolt

36

01601-20513

Washer

37

07285-00200

Clip, Hose

38

205-60-35111

Hose Assembly

|$39

198-60-55510

Breather

39

421-60-35170

Element

40

421-60-35180

Cover

41

421-60-35190

Nut

42

Body

43

Valve Assembly

44

O-ring

45

Case

46

205-00-73360

Plate, Operating

47

01010-81635

Bolt

48

01643-31645

Washer

49

08037-02512

Grommet
