Запчасти Komatsu HB215LC-1 ЦИЛИНДР РУКОЯТИ(№-) ЦИЛИНДР РУКОЯТИ, ЧАС. СМАЗКА INTERVAL

Схема запчастей Komatsu HB215LC-1 - ЦИЛИНДР РУКОЯТИ(№-) ЦИЛИНДР РУКОЯТИ, ЧАС. СМАЗКА INTERVAL
1
3
35
2
17
16
19
23
24
26
27
28
29
11
31
32
30
12
7
13
14
37
38
46
47
49
50
45
4
28
29
32
5
6
4
33
34
36
46
40
42
43
41
39
48
44
47
48
45
50
6
20
22
25
18
15
21
9
8
9
10

Артикул

Название

Примечание

Количество

|$0

707-01-0J251

Cylinder Assembly

|$1

707-01-0J250

Cylinder Assembly

1

707-13-13870

Cylinder

2

707-58-95270

Rod, Piston

3

707-76-80010

Bushing

4

07145-00080

Seal, Dust, (Kit : K05, K06)

5

707-76-80010

Bushing

6

07145-00080

Seal, Dust, (Kit : K05, K06)

7

07020-00000

Fitting, Grease

8

707-71-34980

Collar

9

707-35-31260

Ring, Back-up, (Kit : K05)

9

707-35-91370

Ring, Back-up, (Kit : K06)

10

07000-15125

O-ring, (Kit : K05, K06)

11

707-71-71010

Plunger

12

707-71-80270

Plunger

13

04260-00635

Ball, Steel

14

707-71-91270

Cap

15

707-27-13850

Head, Cylinder

16

707-56-95740

Seal, Dust, (Kit : K05, K06)

17

07179-13109

Ring, Snap

18

707-52-90721

Bushing

19

707-51-95030

Packing, Rod

20

707-51-95650

Ring, Buffer

21

707-35-31260

Ring, Back-up, (Kit : K05)

21

707-35-91370

Ring, Back-up, (Kit : K06)

22

07000-15125

O-ring, (Kit : K05, K06)

23

01010-81875

Bolt

24

707-41-11840

Washer

25

707-75-95030

Ring, Snap

26

707-36-13771

Piston

27

707-44-13250

Ring, Piston, (Kit : K05, K06)

28

707-39-13530

Ring, Wear, (Kit : K05, K06)

29

707-44-13920

Ring

30

01310-01216

Screw

31

07000-15085

O-ring, (Kit : K05, K06)

32

707-35-30850

Ring, Back-up, (Kit : K05)

32

707-35-90960

Ring, Back-up, (Kit : K06)

33

707-83-13010

Valve

34

07750-01628

Spring

35

707-87-14070

Plug

36

07002-12034

O-ring

37

707-86-67740

Tube

38

707-88-22530

Bracket

39

07372-21060

Bolt

40

01643-51032

Washer

41

07372-21045

Bolt

42

01643-51032

Washer

43

07000-13030

O-ring, (Kit : K05, K06)

44

707-88-28030

Bracket

45

01643-31032

Washer

46

707-88-21261

Band

47

07372-21035

Bolt

48

01643-51032

Washer

49

07283-32738

Clip, Pipe

50

01597-01009

Nut

Выбрано товаров: 55
