Запчасти Komatsu HB215LC-1 МЕХАНИЗМ ПОВОРОТА И МОТОР, МОТОР (№-) МЕХАНИЗМ ПОВОРОТА И МОТОР

|$0

7875-13-1013

Motor Assembly

1

7875-13-1203

Motor Assembly

2

7875-13-3830

Valve

3

02781-0031D

Nipple

4

07002-11423

O-ring

5

7875-13-3420

Filter

6

07002-11623

O-ring

7

07000-11010

O-ring

8

07030-01030

Breather

9

203-70-56570

Nipple

10

7875-10-5240

Plug

11

07002-12434

O-ring

12

7875-13-5410

Plug

13

07002-11023

O-ring

14

08193-20010

Clip

15

01010-81025

Bolt

16

01643-31032

Washer

17

04434-50608

Clip

18

01016-50825

Bolt

19

7875-13-3530

Filter

20

07002-12034

O-ring

21

21W-910-4360

Elbow

22

07002-11423

O-ring

23

02783-10422

Elbow

24

07002-12034

O-ring

25

124-49-51430

Joint

26

07002-12034

O-ring

27

7875-13-3551

Elbow

28

07002-12034

O-ring

29

07040-11812

Plug

30

07002-11823

O-ring

31

7875-13-3140

Pipe

32

07000-12035

O-ring

33

01010-80855

Bolt

34

01643-30823

Washer

35

04434-51708

Clip

36

01016-50825

Bolt

37

7875-13-8810

Gauge

38

203-62-14510

Joint

39

07002-12434

O-ring

40

01643-30823

Washer

41

02896-11009

O-ring

42

02896-11012

O-ring
