Запчасти Komatsu HB205-1M0 ГИДР. БАК. (№-) ГИДР. БАК., С БЫСТРОСЪЕМН. МЕХ-М

1

20Y-60-42111

Tank

2

203-60-31100

Elbow Assembly

3

203-60-31160

Tube

4

07044-12412

Plug

5

07002-12434

O-ring

6

23B-60-42910

Tee

7

02896-11018

O-ring

8

02896-11009

O-ring

9

07002-12434

O-ring

10

02782-10311

Elbow

11

02896-11009

O-ring

12

07002-11423

O-ring

13

20Y-62-45690

Tee

14

02896-11009

O-ring

15

02896-11008

O-ring

16

07002-12034

O-ring

17

207-60-71183

Element

18

20Y-60-31140

Strainer

19

20Y-60-31450

Valve Assembly

20

20Y-60-21240

Spring

21

207-60-77131

Cover

22

07000-15195

O-ring

23

01010-81225

Bolt

24

01643-31232

Washer

|$24

20Y-60-31171

Strainer Assembly

25

207-60-61150

Rod Assembly

26

20Y-60-21320

Holder

27

12R-60-11230

Spring

28

22B-60-11160

Strainer

29

20Y-60-42143

Cover

30

07000-15160

O-ring

31

01010-81225

Bolt

32

01643-31232

Washer

33

20Y-60-42220

Cap Assembly

34

20Y-60-42210

Filler Neck

35

20Y-60-21340

Gasket

36

01252-70516

Bolt

37

01601-20513

Washer

38

07285-00200

Clip, Hose

39

205-60-35111

Hose Assembly

|$40

198-60-55510

Breather

40

421-60-35170

Element

41

421-60-35180

Cover

42

421-60-35190

Nut

43

Body

44

Valve Assembly

45

O-ring

46

Case

47

205-00-73360

Plate, Operating

48

01010-81635

Bolt

49

01643-31645

Washer

50

08037-02512

Grommet
