Запчасти Komatsu 245 КАБИНА (3 ЧАСТЬ) ЧАСТИ КОРПУСА И КАБИНА

\0

816101435

OPERATOR'S CAB, ASSY.

1

816213674

FRONT DOOR

2

816213686

STRIKER

3

816213678

GASKET, UPPER

4

816213675

GASKET, LATERAL

5

816213691

SEAL, GLASS-WINDOW

6

816024494

SEAL, FRONT DOOR

7

816024495

GLASS-WINDOW, RUN, FRONT

8

816213676

R.H., GUIDE FRONT GLASS-WINDOW

9

816213677

L.H., GUIDE FRONT GLASS-WINDOW

10

801014046

BOLT

11

802150506

SPRING WASHER

12

802148006

WASHER

13

855711072

LOWER SEAL, FRONT GLASS-WINDOW

14

816212543

SEAL, DOOR

15

816212582

SEAL

16

816024446

GLASS, REAR

17

816210678

PIN, ASSY.

18

816210684

FITTING

19

816213687

PIN

20

816213681

KNOB

21

816213685

SPACER

22

816213680

RETAINER

23

801250028

SCREW

24

801148003

WASHER

25

801852204

NUT

26

816211475

HANDLE, R.H.

27

816211476

HANDLE, L.H.

28

816211479

SPACER

29

816211478

SPACER

30

802070006

WASHER

31

801852206

NUT

32

816213689

COVER

33

816213740

RUBBER

34

816211903

PAD

35

801250045

SCREW

36

816213273

HANDLE

37

816213683

GASKET
