Запчасти Komatsu 245 РАДИАТОР КОМПОНЕНТЫ ДВИГАТЕЛЯ И ЭЛЕКТРИКА

1

3K4007056

RADIATOR, ASSY.

2

3K4007053

PLUG

3

3K4007600

PLUG

4

855661170

O-RING

5

890001201

PIPE

6

3K4007051

CONVEYOR

7

3K4007052

PROTECTION

8

801015084

BOLT

9

802150508

SPRING WASHER

10

802170001

WASHER

11

3K4007055

SUPPORT, L.H.

12

3K4007054

SUPPORT, R.H.

13

801015109

BOLT

14

802170002

WASHER

15

808001036

DAMPER

16

801920105

NUT

17

3K4008600

SLEEVE

18

802660010

HOSE-CLAMP

19

802660007

CLAMP

20

3K4008603

TUBE

21

802660034

COLLAR

22

801015109

BOLT

23

802170002

WASHER

24

852951158

SLEEVE

25

3K4008604

SLEEVE

26

816213103

TANK

27

200535187

SUPPORT, TANK

28

801015064

BOLT

29

802170000

WASHER

30

3K4009600

PIPE

31

802660002

CLAMP

32

802660501

COLLAR

33

801015108

BOLT

34

802170002

WASHER

35

885180012

HOSE-CLAMP

36

200536946

BRACKET

37

3K4040602

SHEET, L.H.

38

3K4040603

SHEET, R.H.

|A

SEE FIG. 7170
