Запчасти Komatsu 245 ГОЛОВКА ЦИЛИНДРОВ - КРЫШКА ДВИГАТЕЛЬ

\0

871070005

MOTOR, ASSY.

1

YMR000576

CYLINDER HEAD

5

YMR000052

GUIDE VALVE

7

YMR000174

GUIDE VALVE

9

YMR000071

PLUG

10

YMR000378

PLUG

11

YMR000435

PLUG

12

YMR000437

PLUG

13

YMR000421

STUD

14

YMR000100

VALVE, INLET

15

YMR000101

VALVE EXHAUST

16

YMR000298

SPRING, VALVE

17

YMR000299

RETAINER, SPRING

18

YMR000004

COTTER

19

YMR000065

SEAL, VALVE EXHAUST

20

YMR000085

SEAL, VALVE STEM

21

YMR000424

NUT

22

YMR000172

CAP VALVE

23

YMR000365

PEG

24

YMR000022

RETAINER

25

YMR000020

PROTECTION, NOZZLE

26

YMR000021

SEAT, NOZZLE

27

YMR000557

SHAFT

28

YMR000549

SHAFT

30

YMR000433

PLUG

31

YMR000203

SUPPORT

32

YMR000204

SUPPORT

33

YMR000169

SPRING

34

YMR000460

ROCKER SHAFT

36

YMR000173

NUT

37

YMR000168

VALVE

38

YMR000423

STUD

39

YMR000574

NUT

40

YMR000404

SCREW

41

YMR000408

SCREW

42

YMR000092

LIFTER

43

YMR000401

BOLT

44

YMR000577

COVER

46

YMR000165

SPLASH-GUARD

47

YMR000166

PROTECTION

48

YMR000389

O-RING

49

YMR000402

BOLT

50

YMR000550

GASKET

51

YMR000164

COVER, BREATHER

52

YMR000384

O-RING

53

YMR000078

PLUG

54

YMR000167

RETAINER

55

YMR000570

PIPE

56

YMR000080

PLUG

57

YMR000382

O-RING

58

YMR000518

RETAINER

59

YMR000568

CLAMP

60

YMR000400

BOLT
