Запчасти Komatsu 245 ТОПЛ. НАСОС ДВИГАТЕЛЬ

Схема запчастей Komatsu 245 - ТОПЛ. НАСОС ДВИГАТЕЛЬ
31
102
105
104
95
110
14
a
a
32
47
48
33
46
28
83
47
12
30
48
46
14
27
12
82
13
35
52
24
19
29
34
13
19
20
52
20
15
8
15
45
44
51
16
43
16
75
41
22
23
23
11
79
42
88
80
87
50
74
49
5
73
77
4
106
90
84
76
72
7
78
85
71
96
94
103
98
85
92
100
81
86
101
36
99
6
1
97
109
111

Артикул

Название

Примечание

Количество

1

YMR000579

PUMP

4

YMR000545

CAMSHAFT ASSY.

5

YMR000207

BEARING

6

YMR000208

COVER

7

YMR000075

KEY

8

YMR000284

PLUNGER W/BARREL

11

YMR000209

PIN

12

YMR000350

RETAINER, SPRING

13

YMR000210

SEAT, NOZZLE SPRING

14

YMR000095

SPRING

15

YMR000211

TAPPET, ASSY

16

YMR000443

ROLLER, ASSY.

19

YMR000212

SCREW

20

YMR000349

PIN, ROLLER

22

YMR000213

LOCKING, TAPPET

23

YMR000214

O-RING

24

YMR000288

VALVE DELIVERY

27

YMR000215

SPRING

28

YMR000216

GUARD, DELIVERY VALVE

29

YMR000087

GASKET

30

YMR000088

O-RING

31

YMR000217

STOPPER

32

YMR000218

LOCKING (A)

33

YMR000219

LOCKING (B)

34

YMR000558

PIPE

35

YMR000221

CHECK BOLT

36

YMR000223

RING

41

YMR000559

RACK

42

YMR000428

NUT

43

YMR000225

BUSHING

44

YMR000226

SPACER

45

YMR000227

RING, SNAP

46

YMR000228

PINION

47

YMR000074

SCREW

48

YMR000351

PINION

49

YMR000229

PLUG

50

YMR000230

O-RING

51

YMR000231

SPRING

52

YMR000232

SHIM

71

YMR000560

COVER

72

YMR000561

GASKET

73

YMR000562

COVER

74

YMR000563

GASKET

75

YMR000237

LOCKING, RACK

76

YMR000260

PLATE, CAUTION

77

YMR000238

SPACER, T=3.25

78

YMR000239

SPACER, T=1.5

79

YMR000357

WASHER

80

YMR000364

PEG

81

YMR000381

BEARING

82

YMR000387

O-RING

83

YMR000415

SCREW

84

YMR000206

STUD

85

YMR000393

SCREW

86

YMR000394

SCREW

87

YMR000222

PLUG

88

YMR000442

GASKET

90

YMR000267

FEED PUMP, ASSY.

92

YMR000262

DIAPHRAGM

94

YMR000263

COVER

95

YMR000264

GASKET

96

YMR000265

SCREW

97

YMR000266

PLUG

98

YMR000268

SPRING

99

YMR000269

TAPPET

100

YMR000270

SPRING

101

YMR000271

PIN

102

YMR000272

LINK

103

YMR000273

SPRING

104

YMR000274

PIN

105

YMR000275

O-RING

106

YMR000240

GASKET

109

YMR000187

FUEL INJECTION GEAR

110

YMR000358

WASHER

111

YMR000429

NUT

Выбрано товаров: 75
