Запчасти Komatsu 235 УПРАВЛЯЮЩ. КЛАПАН (ДЛЯ НАВЕСН. ОБОРУД.) РАБОЧЕЕ ОБОРУДОВАНИЕ

\0

844010210

CONTROL VALVE, ASSY.

1

844100286

BODY DELIVERY

2

844100297

PLUG

3

802090218

WASHER

4

844100285

CAP, ASSY.

5

855021018

O-RING

6

802090212

WASHER

7

801703208

NUT

8

802150508

SPRING WASHER

9

844100284

VALVE ASSY.

10

844100254

VALVE

11

844100255

SPRING

12

855150037

GASKET

13

844100041

PLUG

14

844100298

RELIEF VALVE, ASSY.

15

802090209

GASKET

16

844100257

O-RING

17

802090214

WASHER

18

844100308

ELEMENT, ASSY

19

855021018

O-RING

20

845020222

VALVE, ASSY.

21

855021806

O-RING

22

855021011

O-RING

23

802090212

WASHER

24

844100293

COVER

25

801220193

SCREW

26

844100292

SPRING

27

855021115

O-RING

28

844100291

SUPPORT

29

855350024

GASKET

30

844100290

O-RING

31

855021009

O-RING

32

844100288

PISTON

33

844100289

SPRING

34

855021018

O-RING

35

844100295

PLUG

36

802090222

WASHER

37

844100294

BODY

38

801014809

SCREW

39

844100283

SET OF SEALS
