Запчасти Komatsu 235 СТАРТЕР ДВИГАТЕЛЬ

1

YMR000303

STARTER MOTOR

2

YMR000304

ROTOR,ASSY.

3

YMR000305

BEARING (1)

4

YMR000306

BEARING (2)

5

YMR000307

STATOR

6

YMR000308

COIL ASSY.,FIELD

7

YMR000309

SCREW

8

YMR000310

BRUSH (+)

9

YMR000311

BRUSH HOLDER, ASSY.

10

YMR000312

BRUSH (--)

11

YMR000313

SPRING

12

YMR000314

COVER, REAR

13

YMR000315

FLANGE

14

YMR000316

HOUSING, GEAR

15

YMR000317

SWITCH, MAGNETIC

16

YMR000318

LEVER SET, SHIFT

17

YMR000319

LEVER

18

YMR000320

SPRING

19

YMR000321

DUST PAN, ASSY.

20

YMR000322

COVER (A)

21

YMR000323

COVER (B)

22

YMR000324

COVER (C)

23

YMR000325

COVER (D)

24

YMR000326

COVER (E)

25

YMR000327

COVER (F)

26

YMR000328

SCREW

27

YMR000329

PINION

28

YMR000330

SHAFT

29

YMR000331

KIT, STOP SET, PINION

30

YMR000332

STOPPER SET, PINION

31

YMR000333

SPRING

32

YMR000334

RING, SNAP

33

YMR000335

CLUTCH, ASSY.

34

YMR000336

BEARING (3)

35

YMR000337

BEARING (4)

36

YMR000338

CAP

37

YMR000398

SCREW

38

YMR000399

SCREW

39

YMR000418

BOLT PLATED

40

YMR000154

RELAY, SAFETY

41

YMR000096

TIMER
