Запчасти Komatsu 235 ТОПЛИВН. ЛИНИЯ ДВИГАТЕЛЬ

1

YMR000114

FILTER, ASSY.

2

YMR000007

VALVE, TAPER

3

YMR000008

SPRING

4

YMR000115

CARTRIDGE

6

YMR000116

LINK

7

YMR000117

CUP, STRAINER

8

YMR000118

RING, NUT

9

YMR000119

SPRING

10

YMR000010

SCREW

11

YMR000383

O-RING

12

YMR000385

O-RING

13

YMR000386

O-RING

14

YMR000077

COLLAR

15

YMR000200

CAP

16

YMR000392

SCREW

17

YMR000005

SCREW

18

YMR000001

JOINT

19

YMR000093

COLLAR

20

YMR000011

GASKET

21

YMR000290

PIPE

22

YMR000276

PIPE

23

YMR000370

CLAMP

24

YMR000093

COLLAR

25

YMR000077

COLLAR

26

YMR000061

PIPE

27

YMR000048

PIPE

28

YMR000049

UNION

29

YMR000200

CAP

30

YMR000276

PIPE

31

YMR000121

VALVE, ASSY.

32

YMR000120

KIT, SHIM

39

YMR000375

GASKET

40

YMR000280

WATER SEPARATOR

41

YMR000007

VALVE, TAPER

42

YMR000008

SPRING

43

YMR000009

KNOB

44

YMR000076

BOWL, FUEL STRAINER

45

YMR000003

O-RING

46

YMR000012

RING, NUT

47

YMR000062

SPRING

48

YMR000063

FLOAT

50

YMR000002

PLUG

51

YMR000010

SCREW

52

YMR000341

CARTRIDGE

53

YMR000376

GASKET

54

YMR000385

O-RING
