Запчасти Komatsu 235 РЕГУЛЯТОР ДВИГАТЕЛЬ

1

YMR000214

O-RING

4

YMR000241

HOUSING

5

YMR000242

GASKET

6

YMR000243

COVER

7

YMR000244

GASKET

8

YMR000245

LINK L=30 (0)

9

YMR000246

LINK L=31 (1)

10

YMR000247

LINK L=30.5 (0.5)

11

YMR000248

WEIGHT ASSY., GOVERNOR

15

YMR000249

SLEEVE

16

YMR000122

SHAFT, CONTROL

19

YMR000250

SPACER

23

YMR000123

HANDLE

24

YMR000124

TORQUE SPRING ASSY.

30

YMR000251

BOLT, REVOL. LIMIT

37

YMR000252

BOLT, IDLE LIMIT

38

YMR000253

SPACER

43

YMR000254

SHAFT

44

YMR000287

GOVERNOR LEVER, ASSY.

45

YMR000350

RETAINER, SPRING

58

YMR000255

BUSHING

62

YMR000256

SHIFTER

63

YMR000125

SPRING

64

YMR000348

SPRING, REGULATOR

65

YMR000278

LEVER, STOP

66

YMR000257

PIN

67

YMR000126

SPRING

68

YMR000258

O-RING

69

YMR000259

SCREW

70

YMR000090

NUT

71

YMR000354

WASHER

72

YMR000359

RING, SNAP

73

YMR000360

RING, SNAP

74

YMR000361

WASHER

75

YMR000362

PIN

76

YMR000366

PIN, SNAP

77

YMR000380

PLUG

78

YMR000385

O-RING

79

YMR000393

SCREW

80

YMR000397

BOLT

81

YMR000425

NUT

82

YMR000427

CAP NUT

83

YMR000430

NUT

84

YMR000431

NUT

85

YMR000438

GASKET

86

YMR000440

GASKET

87

YMR000441

GASKET

88

YMR000302

LEAD

89

YMR000368

CABLE

|A

SEE FIG. 1150
