Запчасти Komatsu 230 2-Х СЕКЦИОНН. УПРАВЛЯЮЩ. КЛАПАН УПРАВЛ-Е РАБОЧИМ ОБОРУДОВАНИЕМ

\0

844230007

CONTROL VALVE, ASSY.

1

844120242

KIT, TIE-ROD

2

844120203

INLET ELEMENT, ASSY.

3

844120207

MAIN RELIEF VALVE, ASSY.

4

844120208

KIT, VALVE GASKET

5

844120205

PLUG

6

844120206

ORIFICE DISK

7

844120204

SPRING

8

844120240

BLADE SECTION, ASSY.

9

844120220

KIT, GASKET

10

844120222

PLATE, ASSY.

11

844120221

WASHER

12

844120212

PLUG

13

844120213

SPRING

14

844120211

VALVE

15

844120223

SPOOL RETURN UNIT

16

844120224

SPRING

17

844120236

CAP, ASSY.

18

844120237

KIT, GASKET

19

844120217

SAFETY AND SUCTION VALVE, ASSY.

20

844120218

KIT, GASKET

21

844120241

SWING SECTION, ASSY.

22

844120210

KIT, GASKET

23

844120214

CONTROL UNIT, ASSY.

24

844120215

SPRING

25

844120216

SPRING

26

855021021

O-RING

27

844120212

PLUG

28

844120213

SPRING

29

844120211

VALVE

30

844120233

A/C VALVE, ASSY.

31

844120218

KIT, GASKET
