Запчасти Komatsu 230 КОЖУХ ШЕСТЕРЕН. ПЕРЕДАЧИ ДВИГАТЕЛЬ
A
15
9
2
19
14
3
4
14
10
11
8
1
23
22
24
17
21
13
5
16
18
7
6
20
12
1
YMR000282
CASE
2
YMR000283
FLANGE
3
YMR000066
STUD
4
YMR000078
PLUG
5
YMR000295
SEAL, OIL
6
YMR000083
COVER
7
YMR000084
GASKET, BONNET
8
YMR000296
PIPE
9
YMR000073
O-RING
10
YMR000383
O-RING
11
YMR000384
O-RING
12
YMR000400
BOLT
13
YMR000402
BOLT
14
YMR000402
BOLT
15
YMR000403
BOLT
16
YMR000407
BOLT
17
YMR000409
BOLT
18
YMR000412
SCREW
20
YMR000439
GASKET
21
YMR000439
GASKET
22
YMR000053
COVER
23
YMR000388
O-RING
24
YMR000395
SCREW
