Запчасти Komatsu 230 ТОПЛ. НАСОС ДВИГАТЕЛЬ

1

YMR000449

PUMP, ASSY.

4

YMR000024

CAMSHAFT

5

YMR000207

BEARING

6

YMR000208

COVER

7

YMR000075

KEY

8

YMR000284

PLUNGER W/BARREL

11

YMR000209

PIN

12

YMR000350

RETAINER, SPRING

13

YMR000210

SEAT, NOZZLE SPRING

14

YMR000095

SPRING

15

YMR000211

TAPPET, ASSY

16

YMR000443

ROLLER, ASSY.

20

YMR000212

SCREW

21

YMR000349

PIN, ROLLER

22

YMR000213

LOCKING, TAPPET

23

YMR000214

O-RING

24

YMR000288

VALVE DELIVERY

27

YMR000215

SPRING

28

YMR000216

GUARD, DELIVERY VALVE

29

YMR000087

GASKET

30

YMR000088

O-RING

31

YMR000217

STOPPER

32

YMR000218

LOCKING (A)

33

YMR000219

LOCKING (B)

34

YMR000220

DEFLECTOR

35

YMR000221

CHECK BOLT

36

YMR000222

PLUG

37

YMR000223

KIT, SHIM

42

YMR000224

RACK

43

YMR000225

BUSHING

44

YMR000226

SPACER

45

YMR000227

RING, SNAP

46

YMR000228

PINION (B)

47

YMR000074

SCREW

48

YMR000351

PINION

49

YMR000229

PLUG

50

YMR000230

O-RING

51

YMR000231

SPRING

52

YMR000232

SHIM

71

YMR000233

COVER

72

YMR000234

GASKET

73

YMR000235

COVER

74

YMR000236

GASKET

75

YMR000237

LOCKING, RACK

76

YMR000260

PLATE, CAUTION

77

YMR000238

SPACER T=3.25

78

YMR000239

SPACER T=1.5

79

YMR000356

SPRING WASHER

80

YMR000357

SPRING WASHER

81

YMR000364

PEG

82

YMR000381

BEARING

83

YMR000387

O-RING

84

YMR000393

SCREW

85

YMR000394

SCREW

86

YMR000415

SCREW

87

YMR000206

STUD

88

YMR000428

NUT

89

YMR000442

GASKET

90

YMR000240

GASKET

91

YMR000267

FEED PUMP, ASSY.

93

YMR000262

DIAPHRAGM

95

YMR000263

COVER

96

YMR000264

GASKET

97

YMR000265

SCREW

98

YMR000266

PLUG

99

YMR000268

SPRING

100

YMR000269

TAPPET

101

YMR000270

SPRING

102

YMR000271

PIN

103

YMR000272

LINK

104

YMR000273

SPRING

105

YMR000274

PIN

106

YMR000275

O-RING

107

YMR000187

FUEL INJECTION GEAR

108

YMR000358

WASHER

109

YMR000429

NUT
